Scame кабели за зареждане на електромобили – Type 2

Scame кабели за зареждане на електромобили – Type 2

Кабели за зареждане на електромобили Scame

Ергономичен дизайн за по-голямо удобство на потребителя



оцени серията
оценка 0 от 0 гласували

Кабелният комплект е предназначен за свързване на автомобила към зарядната станция. Състои се от щепсел за връзка от страна на зарядната инфраструктура, конектор (подвижно гнездо) – от страна на автомобила, кабел с подходящо напречно сечение и превключвател на полярността, предвиден за мобилна употреба, който е високоустойчив на тежки работни условия. В сравнение с вариантите, включващи кабел, фиксиран към превозното средство, и тези с кабел, прикрепен към станцията за зареждане, настоящата конфигурация е значително по-гъвкава благодарение на съвместимостта с популярните глобални стандарти за свързаност.

Всички комплекти включват специални кабели, подходящи за електромобили, които са съвместими с приложимия стандарт EN 50620.



  • COD. 201.CS0021-4S

Technical characteristics

•  Rated current: 20 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Max power: 3,7kW

•  Material: Thermoplastic

•  Cable length: 4 m

•  Cable: Spiral



  • COD. 201.CS0021-5

Technical characteristics

•  Rated current: 20 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Max power: 3,7 kW

•  Material: Thermoplastic

•  Cable length: 5 m



  • COD. 201.CS0021-8

Technical characteristics

•  Rated current: 20 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Max power: 3,7 kW

•  Material: Thermoplastic

•  Cable length: 7,5 m



  • COD. 201.CS2111-5

Technical characteristics

•  Rated current: 20 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 3,7 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable length: 5 m

Cable

•  Rated voltage: 450/750V

•  Insulation/Sheath: PUR

•  Max. temperature: +90°C



  • COD. 201.CS2111-8

Technical characteristics

•  Rated current: 20 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 3,7 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable length: 7,5 m

Cable

•  Rated voltage: 450/750V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C



  • COD. 201.CS2121-4S

Technical characteristics

•  Rated current: 20 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 3,7 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable: Spiral

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C

•  Max. extension: 4 m



  • COD. 201.CS2121-5

Technical characteristics

•  Rated current: 20 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 3,7 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable length: 5 m

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C



  • COD. 201.CS2121-8

Technical characteristics

•  Rated current: 20 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 3,7 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable length: 7,5 m

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C



  • COD. 201.CSA121-5

Technical characteristics

•  Rated current: 20 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 3,7 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable length: 5 m

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C



  • COD. 201.CS0023-4S

Technical characteristics

•  Rated current: 32 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Max power: 7,4 kW

•  Material: Thermoplastic

•  Cable length: 4 m

•  Cable: Spiral



  • COD. 201.CS0023-5

Technical characteristics

•  Rated current: 32 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Max power: 7,4 kW

•  Material: Thermoplastic

•  Cable length: 5 m



  • COD. 201.CS0023-8

Technical characteristics

•  Rated current: 32 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Max power: 7,4 kW

•  Material: Thermoplastic

•  Cable length: 7,5 m



  • COD. 201.CS2313-5

Technical characteristics

•  Rated current: 32 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 7,4 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable length: 5 m

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C



  • COD. 201.CS2313-8

Technical characteristics

•  Rated current: 32 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 7,4 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable length: 7,5 m

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C



  • COD. 201.CS2323-4S

Technical characteristics

•  Rated current: 32 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 7,4 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable: Spiral

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C

•  Max. extension: 4 m



  • COD. 201.CS2323-5

Technical characteristics

•  Rated current: 32 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 7,4 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable length: 5 m

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C



  • COD. 201.CS2323-8

Technical characteristics

•  Rated current: 32 A

•  Rated voltage: 230 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 7,4 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable length: 7,5 m

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C



  • COD. 201.CS0022-4S

Technical characteristics

•  Rated current: 20 A

•  Rated voltage: 400 V

•  Protection degree: IP44

•  Max power: 11 kW

•  Material: Thermoplastic

•  Cable length: 4 m

•  Cable: Spiral



  • COD. 201.CS0022-5

Technical characteristics

•  Rated current: 20 A

•  Rated voltage: 400 V

•  Protection degree: IP44

•  Max power: 11 kW

•  Material: Thermoplastic

•  Cable length: 5 m



  • COD. 201.CS0022-8

Technical characteristics

•  Rated current: 20 A

•  Rated voltage: 400 V

•  Protection degree: IP44

•  Max power: 11 kW

•  Material: Thermoplastic

•  Cable length: 7,5 m



  • COD. 201.CS2222-4S

Technical characteristics

•  Rated current: 20 A

•  Rated voltage: 400 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 11 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable: Spiral

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C

•  Max. extension: 4 m



  • COD. 201.CS2222-5

Technical characteristics

•  Rated current: 20 A

•  Rated voltage: 400 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 11 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable length: 5 m

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C



  • COD. 201.CS2222-8

Technical characteristics

•  Rated current: 20 A

•  Rated voltage: 400 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 11 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable length: 7,5 m

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C



  • COD. 201.CS0024-4S

Technical characteristics

•  Rated current: 32 A

•  Rated voltage: 400 V

•  Protection degree: IP44

•  Max power: 22 kW

•  Material: Thermoplastic

•  Cable length: 4 m

•  Cable: Spiral



  • COD. 201.CS0024-5

Technical characteristics

•  Rated current: 32 A

•  Rated voltage: 400 V

•  Protection degree: IP44

•  Max power: 22 kW

•  Material: Thermoplastic

•  Cable length: 5 m



  • COD. 201.CS0024-8

Technical characteristics

•  Rated current: 32 A

•  Rated voltage: 400 V

•  Protection degree: IP44

•  Max power: 22 kW

•  Material: Thermoplastic

•  Cable length: 7,5 m



  • COD. 201.CS2424-4S

Technical characteristics

•  Rated current: 32 A

•  Rated voltage: 400 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 22 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable: Spiral

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C

•  Max. extension: 4 m



  • COD. 201.CS2424-5

Technical characteristics

•  Rated current: 32 A

•  Rated voltage: 400 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 22 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable length: 5 m

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C



  • COD. 201.CS2424-8

Technical characteristics

•  Rated current: 32 A

•  Rated voltage: 400 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 22 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable length: 7,5 m

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C



  • COD. 201.CSC424-5

Technical characteristics

•  Rated current: 32 A

•  Rated voltage: 400 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 22 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable length: 5 m

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C



  • COD. 201.CSC424-8

Technical characteristics

•  Rated current: 32 A

•  Rated voltage: 400 V

•  Protection degree: IP44

•  Operating temperature: - 30°C + 50°C

•  Max power: 22 kW

•  Material: Thermoplastic

•  Salt mist: Resistant

•  UV radiation: Resistant

•  Cable length: 7,5 m

Cable

•  Rated voltage: 450/750 V

•  Insulation/Sheath: PUR

•  Max. temperature: + 90°C
