Murrplastik EW-PAE

The EW-PAE cable protection conduits are made of specially modified polyamide 12. The material is halogen, phosphor and cadmium-free. The EW-PAE cable protection conduits are characterised by excellent flexibility, flexural fatigue strength and good crush resistance. For extremely dynamic applications involving medium mechanical loads.

• Applications

• Robotics

• Handling systems

• in cable drag chains

• Specifications

• mod. polyamide PA 12

• --40 °C–120 °C short term 150 °C

• acc. to UL94: HB

• > 500 N According to IEC EN 61386 M25/P21

• 4 According to IEC EN 61386 M25/P21

• Cycles: > 5000000 ~

• 4 According to IEC EN 61386 M25/P21

• > 150 N According to IEC EN 61386 M25/P21

• alcohol, greases, fuels, lyes, mineral oils, weak acids
