Schneider Electric EcoStruxure Operator Terminal Expert (Vijeo XD)

Schneider Electric EcoStruxure Operator Terminal Expert (Vijeo XD)

Configuration software for Harmony ranges supporting gestures and intuitive user interface designs

EcoStruxure Operator Terminal Expert configuration software enables you to create and edit HMI Runtime application in Harmony HMIs and iPCs by Schneider Electric

  • Common features:

• Variables - Create the variables you need, and then associate variables with switches, lamps, data displays, and other objects on the screen.
• Alarm - Alarm Summary displays information such as alarm message, type of alarm, and date and time when the alarm was reported or restored.
• Operation Logs - Maintaining a log of operations on the panel is useful in analyzing the root cause of problems, such as operations executed before an error is detected. •   • User Management can be used to identify the person operating the system.
• Data Logging and Trend Graph - Data logging collects and stores values in device addresses associated with variables.
• Recipes - Recipe feature allows easy transfer of parameter settings into target device addresses. Define Recipe settings in buildtime and have flexible change management in runtime.
• Security - Security feature secures objects from unauthorized access. Log in with a valid user name and password to access secured objects. Auto-logout supported.
• Converter - Change the value of a variable from the defined unit, range, scale, and expression.
• Remote Monitoring - Allow remote monitoring of HMI device over the network on standard browsers that is supported by multiple device platforms.



  • Compatibility:

• EcoStruxure Operator Terminal Expert allows you to create and edit application screens that control automation systems for Harmony GTU (Premium and Open Box)/STO color/ST6/STM6 terminals, and Harmony industrial PCs (Panel and Box)



  • Benefits:

• EcoStruxure Operator Terminal Expert software helps designers and operators to maximize efficiency through modern functionalities and user-friendly features



  • Operate intuitively:

• Multi-touch zoom in/zoom out, slide, pinch, and stretch options similar to smartphones for enhanced user experience
• With special navigation features like scrolling panel and zoom in/zoom out panel, more information can be accessed and viewed in a single page
• Information-rich objects providing easy and direct access to device information and database
• Improved efficiency for HMI operators with clear design such as new object properties



  • Reduce time to market:

• Minimize design time with pre-defined navigation and easy to locate tab management
• Fast customization and product differentiation can be achieved by using prepared Themes and Color-set
• Scripting made easy for everyone, just drag and drop the target objects to canvas



  • Improved visualization:

• High image quality and usability for modern look and feel



  • EcoStruxure Operator Terminal Expert provides integral visibility through the EcoStruxure architecture:

• Data Dictionary support for automatic updates between Schneider Electric PLCs and the HMI database
• No need to manually change the HMI project



  • Symbol sharing together with EcoStruxure Machine Expert (formerly known as SoMachine) and EcoStruxure Control Expert (formerly known as Unity Pro) PLCs:

• Supported file formats: smbp/xml/xvm/xsy
• Supports unallocated variables too



  • EcoStruxure Secure Connect Advisor



  • Secure access to HMI over the internet for maintenance, control and monitoring



  • EcoStruxure Augmented Operator Advisor:

• Augmented reality for instant diagnosis and contactless maintenance, for increased efficiency and lower costs



  • Applications
    OEM building simple machines and Automation Panel Builder applications for:

• Food & Beverage
• Packaging
• Textile
• Compressor/Pump/Fan
• HVAC equipment
• Marine
• WWW
