Mitsubishi Electric EcoMonitorPlus

Mitsubishi Electric EcoMonitorPlus

Енергоспестяващ модул за измерване на енергия

Product for measuring the quantity of energy.

  • Feature 1

Additional units (Optional unit, Extension unit) be added to expand systems in "building block" style.

building block



  • Feature 2

• By combining the control unit (EMU4-CNT-MB) and extension unit, it is possible to automatically control the equipment in conjunction with the measured values!
• By using a dedicated engineering tool (EMU4-KNET), control can be performed simply by setting control parameters!
*Dedicated engineering tools can be downloaded from the FA Global site.

logging



Control details *1 Description
Scheduled control The control unit sends the contact signal to the equipment based on the time schedule.
The 24hour based time schedule have to be set in advance.
Interlocked control

Control by contact signal : The control unit sends the contact signal determined by comparing the collected data with target value, comparing collected data with each other or comparing the status of contacts.

Analog output control      : With this function, the analog output value corresponding to the measured value is calculated and controlled by presetting the upper and lower limits of the measuring value.

Compressor control *2 This function performs energy-saving operation by switching the compressor’s operation mode (operation (load state), operation (unload) state, stop state) to achieve the optimum piping pressure. Two to four compressor units can be controlled.

*1: The minimum control cycle based on the collected monitoring data is one minute. For details, refer to the instruction manual.

*2: The compressor that shifts to each operation mode in response to the contact output state shown below is the compressor that can be connected and controlled.

Contact Compressor operation mode
Operation (load) state Operation (unload) state Stop state
Load Unload ON OFF OFF
Operation ON ON OFF
Stop ON ON OFF



  • Feature 3

• Collect energy data into a SD memory card from EcoMonitorPlus or EcoMonitorLight.
• Logging Unit Utility can make a report from collected data in SD memory card.

logging



  • Feature 4

Monitoring the trends in electric leakage, load current, and temperature allows you to perform preventive maintenance to avoid equipment failure.

These types of equipment require preventive maintenance :

• Equipment that can result in significant loss if it fails.

• Equipment that runs continuously or for many hours.

• Equipment with cables that easily deteriorate due to moisture or oil.

maintenance



  • Method of leakage current measurement (Io and Ior measurements)

Method of leakage current measurement



  • Feature 5

Monitor the failure signs of equipment with analog input unit.

Case study of automobile manufacturer :

• To monitor the failure signs of important equipment, measure "current, temperature, vibration" of motor.

• Trend monitoring with the data collected by PLC and output an alarm to indicators.

analog input



  • Feature 6

Total energy management is realized by loading data of air, gas, water and other consumption as well as electric energy.

total energy management

  • Engineering Tool for EcoMonitorPlus Control UnitSetting Software for EcoWebServer III

This software is for writing control settings, monitoring control state / extension unit mearing value, and collecting event log from terminal.

Software Download - emu4knet.zip



  • How to download Engineering Tool for EcoMonitorPlus Control Unit

• Touch the Engineering Tool for EcoMonitorPlus Control Unit with your mouse and then click the left mouse button.
• Select the place where the file will be saved.
• Open the Explorer and double click the compressed file that is saved.
- Double click "Setup.exe"
• Select "Next" or "Yes"



  • Display Sample

sample



  • Remote Monitoring Tool for EcoMonitorPlus Control Unit

This software is for monitoring control status and manually controlling the Control Unit connected to MITSUBISHI Energy Saving Data Collecting Server (EcoWebServer III).

Software Download - emu4_remote_monitor_v100.zip



  • Processes from download to installation

It is possible to use this software by unzipping downloaded compressed file and copying it onto an arbitrary place (C:\Mitsubishi folder etc.).
Installation of Remote Monitoring Tool is unnecessary.

• Do NOT copy it onto the program folder (C:\Program Files folder and C:\Program Files(x86) folder).
It may not operate normally.
• Do NOT rename or delete the folders or files. It shall not operate normally.



  • Display Sample

sample



  • System Configuration

System Configuration



  • Logging Unit Utility

Logging Unit Utility is the software for EcoMonitorLight/Plus to create reports and setting data file.

Software Download - logging_unit_utility_v110.zip
Software Manual Download - IB63A26-A



  • How to Downloads Logging Unit Utility

• Touch the Logging Unit Utility file with your mouse and then click the left mouse button.
• Select the place where the file will be saved.
• Open the Explorer and double click the compressed file that is saved.
• Copy the "LoggingUnitUtility" folder to any folder.



  • Display Sample

sample
